Ego 55 Flat walk-over stainless 14° 3000K Square

IP65/67

Downloadable files

3D Model
  • Ego 55 Flat Walk-Over Square.3ds
  • Ego 55 Flat Walk-Over Square.stp
Silhouette
  • Ego 55 WO.jpg
Instructions
  • Istruzioni_montaggio
IES Europe
  • T40003SPW00.IES
IES USA
  • T40003SPW00.IES
LDT File
  • T40003SPW00.LDT
LDT PDF
  • T40003SPW00.PDF
FEATURES
  • Product Code: T40003SPW00
  • Material: Steel tempered glass, polymer
  • Series: Architectural Outdoor
  • Area contract: null, Outdoor
  • design by: Studio Artemide
LUMINAIRE
  • Power Supply: Electronic unintegrated
  • Watt: 1,2W
  • Delivered lumen output: 83lm
  • CCT: 3000K
  • Efficiency: 80%
  • Efficacy: 83.00lm/W
  • CRI: 80
DIMENSIONS
  • Diameter: 55 mm
  • Base Length: 122 mm
  • Base Width: 122 mm
  • Recessed depth: 60 mm
  • Cutout shape: Squared
  • Impact Resistance: IK10
SOURCES INCLUDED
  • Category: Led
  • Number: 1
  • Watt: 1W
  • Delivered lumen output: 83lm
  • Color temperature (K): 3000K
  • CRI: 80
  • Color Tolerance: MacAdam 4SDCM
  • Efficacy: 69lm/W
  • Service Life: L70(10K) > 60500h
Notes

Flood opticWide luminous flow suitable for lighting large areas.

Accessories
CONTROCASSA EGO 55
NL40021H0
Driver - 14W - 350mA - IP67 - 79x38x25 (LxWxH) - Undimmable
DV3001
Driver 38W - 220-240 - 185x35x33 (LxWxH) - IP67 - Dimmable DALI
DV1042
