Ciclope Recessed Rust

IP65

Downloadable files

2D Model
  • Ciclope parete.dwg
  • Ciclope parete.dxf
3D Model
  • Ciclope parete.3ds
  • Ciclope parete.stp
Silhouette
  • Ciclope incasso.jpg
Instructions
  • Istruzioni_montaggio_incasso
DiaLux ULD File
  • T081510.uld
IES Europe
  • T081510.IES
IES USA
  • T081510.IES
LDT File
  • T081510.LDT
LDT PDF
  • T081510.pdf
Other
  • T081510.PDF
FEATURES
  • Product Code: T081510
  • Colour: Rust
  • Installation: Recessed, Wall
  • Material: Composite technopolymer, polycarbonate, steel, aluminum
  • Series: Architectural Outdoor
  • Environment: Outdoor
  • Area contract: null, Outdoor, Residential
  • Emission: Direct
  • design by: Alessandro Pedretti
LUMINAIRE
  • Power Supply: Electronic
  • Watt: 6,5W
  • Voltage: 220-240V
  • Delivered lumen output: 383lm
  • CCT: 3000K
  • Efficiency: 64%
  • Efficacy: 63.79lm/W
  • CRI: 90
DIMENSIONS
  • Length: 170 mm
  • Width: 190 mm
  • Height: 270 mm
SOURCES INCLUDED
  • Category: Led
  • Number: 1
  • Watt: 6,5W
  • Color temperature (K): 3000K
  • CRI: 80
Accessories
CICLOPE PARETE CASSAFORMA X INCASSO
T081600
Download all Data sheet PDF
